MUTE+® board - Ceiling Absorber

The Classic among polyester absorbers

  • Health

    Mineral fibre free

    Allergy-friendly

    Tested for harmful substances according to Oeko-Tex® Standard 100

  • Quality

    Highly compressed, pure polyester
    Dimensionally stable, despite low weight
    Length: 300 to 3,000 mm
    Height: 300 to 1,500 mm
    Diameter: 300 to 1,500 mm
    Thickness: 24 mm / 40 mm

  • Acoustics

    Absorption class: B and A

    αw: 1.00 Sound absorption coefficient according to DIN EN ISO 354
    Evaluation according to ISO 11654/ ASTM C423
View full details

Assembly

Time-saving thanks to simple installation with a delicate, continuously adjustable rope suspension.

CAD-Details

Acoustic performance

Room noise is reduced and speech intelligibility is optimised.
Become a sound artist and experience the data of silence in our acoustic calculator.

Acoustic calculator

MUTE+® board S/R24-C⼁S/R40-C

Material

  • Material: Highly compressed, pure polyester
  • Property: Dimensionally stable, low weight
  • Length: 300 to 3,000 mm
  • Height: 300 to 1,500 mm
  • Diameter: 300 to 1,500 mm

Strength 24 mm:

  • Structure: multi-layer
  • Weight: approx. 3,000 g/m²

Strength 40 mm:

  • Structure: 3 layers
  • Weight: approx. 4,000 g/m²

Form

  • Round or with 90° corners
  • Variable shapes possible

Colours

  • White - Gloss level: 4 - 5 GU
  • Grey marbled - Gloss level: 3 - 4 GU
  • Darkgrey marbled - Gloss level: 2 - 3 GU
  • Nightgrey marbled - Gloss level: 1 - 2 GU
  • Black - Gloss level: 1 - 2 GU

Additional Equipment

  • With digital printing
  • With cutouts for built-in components

Acoustics

  • Absorption class: B and A
  • αw: 0.80 to 1.00
  • Sound absorption coefficient according to DIN EN ISO 354; evaluation according to ISO 11654/ ASTM C423

Sustainability

  • 100% recyclable
  • 100% reusable

Health

  • Mineral fiber-free
  • Allergy-friendly
  • Tested for harmful substances according to Oeko-Tex® Standard 100

Building Material Class

  • Building material class DIN 4102: B1

Additional Information

Download

MUTE+® brochure

S40 / R40 | Data sheet | Ceiling | MUTE+® board S40-C (square)/R40-C (round)

Absorber class: A, αw: 1.00 | 1,000 x 1,000 mm, 3 pieces, total height: 240 mm

Absorber class: A, αw: 1.00 | 1,500 x 1,000 mm, 3 pieces, total height: 240 mm

Absorber class: A, αw: 1.00 | 2,000 x 1,000 mm, 3 pieces, total height: 240 mm

R40 | Absorber class: A, αw: 1.00 | ø 750 mm, 3 pieces, total height: 240 mm

R40 | Absorber class: A, αw: 1.00 | ø 1,000 mm, 3 pieces, total height: 240 mm

R40 | Absorber class: A, αw: 1.00 | ø 1,250 mm, 3 pieces, total height: 240 mm

R40 | Absorber class: A, αw: 1.00 | ø 1,500 mm, 3 pieces, total height: 240 mm

We will be happy to provide you with further acoustic data upon request.

Notes

The visual appearance of the colours and structures may vary depending on the monitor, printing, lighting conditions and other environmental factors. Take the opportunity to order a sample and experience for yourself how it matches your expectations.
