Name: MUTE+® metal
Brand: MUTE+® Schallabsorber
SKU: 00106880
Availability: InStock

For organisational reasons, our products cannot currently be purchased directly in the shop.

We look forward to your inquiry.

inquire now

Characteristics

Material

Frame:
Material: Aluminium extruded profile, mitred and invisibly connected

Material:
Material: Polyester/Wool
Lightfastness: Grade 4-6 according to DIN EN ISO 105-B02
Rubbing fastness: grade 3-5 according to DIN EN ISO 105-X12

Acoustics

Absorption class: B and A

αw: 0.80 to 1.00 sound absorption coefficient according to DIN EN ISO 354
Evaluation according to ISO 11654/ ASTM C423

Material

Stretched over the aluminum frame on the outside and can be vacuumed.

Health

Mineral fibre free

Allergy-friendly

Tested for harmful substances according to Oeko-Tex® Standard 100

Building material class

Depends on the fabric selection.

tex100-300
Building material class DIN 4102: B1

tex400-499
Building material class DIN 4102: B2

Upon request
Building material class DIN 4102: A2

Assembly

Easy installation with a tool-free adjustable rope system.

Ceiling mounting:
Raw concrete ceiling:
Create a ø5 drill hole with a minimum depth of 45 mm.
Screw the rope holder to the bare concrete ceiling using a concrete screw (included in delivery).
Wooden ceiling:
Create a ø3.5 drill hole with a minimum depth of 45 mm.
Screw the rope holder to the wooden ceiling using a concrete screw (included).

Absorber mounting:
The lower part of the cable hanger is attached to the rear mounting rail of the absorber (supplied loose) using the threaded pin and sliding nut (included). The mounting rail is screwed to the rear of the aluminum profile frame using drilling screws (included).

Individual dimensions

Length: Up to 3,500 mm

Width: Up to 1,200 mm

Further dimensions can be realised at any time.

Talk to us.

delivery time

We produce the sound absorbers according to your requirements.

If you order up to 15 units, you will receive your absorbers within 3 weeks. For larger quantities, please enquire in advance.

Due to the material situation, it cannot be ruled out that there may be delivery difficulties with the absorber. You will receive your delivery date with the order confirmation.

Notes

The representation of colours and structures is not binding, as brightness and contrast can vary depending on the monitor and printing. Differences are therefore possible. Other materials are available on request.

Due to different production batches, colour differences in the fabrics can inevitably occur.
The batch discrepancy is not a reason for complaint.

Any discolouration caused by clothing fabrics on our fabrics is a defect in the clothing fabric. Since the polluter pays principle applies here, discolouration of textiles is excluded from any manufacturer's guarantee.
